HWDL-350 Mud/air Drilling Rig

Factory Direct
Training on Arrival
One-year warranty
Drilling depth: 300m
Drilling diameter: 75-350mm
Engine Power: 58Kw
Product Introduction

HWDL-350 series drilling rig is a high-efficiency and multi-functional drilling equipment, mainly suitable for drilling wells, agricultural irrigation wells, geothermal air conditioning holes and other wells, especially suitable for water intake projects in mountainous areas and rock formations.

Main feature:

1. Reasonable power engine can save fuel while ensuring stable and high performance;

2. High-quality hydraulic components and strict assembly process ensure the high efficiency of the hydraulic system;

3. Using international high-standard raw materials to ensure the stability of the car body;

4. The design has an industrial aesthetic.

ModelHWDL350
Drilling depth300m (152mm~203mm)
Rope core-drilling 75mm bore diameter450~500m
Drilling diameterØ75~Ø350mm
Drilling angle90°
Mud pumpBW160/ BW200/ BW250
Walking Speed0~2 km/h
GradeabilityMax. 25°~30°
Transport dimension5400*1600*2600mm
Working state dimension3480*1600*7300mm
Machine weight5800kg

Due to the continuous update and progress of technology, technical parameters and configurations are subject to actual delivery.

Submit the form to get the latest parameters and quotes.


Company Profile

Shandong Hengwang Group, founded in 2011 in the cultural city of Jining, Shandong, has grown into a comprehensive innovative technology enterprise integrating R&D, production, trade, and logistics. With a factory area exceeding 300,000 square meters and over 2,000 employees, the company completed and put into operation its billion-yuan Intelligent Manufacturing Base in 2024, reinforcing its strong manufacturing foundation.

Adhering to an "innovation-driven, quality-first" philosophy, Hengwang develops and exports over 40 categories of machinery products to more than 180 countries and regions. Holding over 200 patents and multiple international certifications, the company provides customers with integrated solutions and high-quality service, consistently striving towards its vision of building a century-old brand with outstanding value.
